Model No: TEK620017
• For safely storage of LPG and compressed gas cylinders
• Fire-resistant design and meet safety regulations
• Factory direct and timely delivery
• Flat package to save freight charge
1. Widely used to store aerosol tanks, LPG cylinders and high-pressure gas cylinders (mixed gas), to meet the needs of most gas cylinder storage users.
2. Suitable for chemical companies, factories, warehouses and other related places;
3. Sides and doors are made of frame and steel mesh, which provides ventilation on all sides;
4. Durable yellow powder coating with warning effect, suitable for both indoors and outdoors;
5. Stacked flat packaging, greatly reducing transportation costs.
6. Capable of being moved by a forklift for relocation if required. Note - only when cage is empty of cylinders;
7. Adjustable safety retention chains to help secure cylinders in upright position;
8. Supporting feet attached to the bottom for fixing cabinet to floor (hardware not included);
9. Magnetic door catches to hold doors closed when not locked;
Model No. | TEK620017 |
Color | Yellow |
Material Specifications | Steel frame and steel mesh |
Cylinder Type | LPG& Compressed Gas |
Cylinder Position | 8 horizontal and 9 vertical cylinder |
Numbers of Cylinder | |
Racks | 3 |
Ext. Dimension (WxDxH/mm) | 1524x762x1822 |
Packing Dimension (LxWxH/mm) | 1600x800x180 |
Gross Weight (Kgs) | 165 |
