Corrosive/ Acid Safety Cabinet, 45 Gallon, Yellow, Double Door, Manual/Self-closing Door Type (45 Gal/170 L)
Home | Product Category | Safety Storage Management | Corrosive Cabinets

Corrosive/ Acid Safety Cabinet, 45 Gallon, Yellow, Double Door, Manual/Self-closing Door Type (45 Gal/170 L)

Model No: TEK610045/ TEK610045S

Key Features

• For safe storage of acids, bases and solvents

• Storage capacity of 45 Gal (170L) of corrosive and acid chemicals

• Fire-resistant design and meet safety regulations

• Factory direct and timely delivery

• Customized size available

Inquiry Now
Description Specification Accessories Product Packing Get A Quote
Description

•  Designed to meet OSHA and NFPA standards;

•  1.0 mm thickness high-quality steel sheet with anti-corrosive and moisture-proof coating;

•  Double-layer steel sheet welded structure, with a 38mm insulation in the middle for fire resistance;

•  High quality galvanized steel door hinges to reach 180 degree door-opening;

•  Three-point door latch makes the door open and close more flexible and stable;

•  Adjustable galvanized steel shelves and shelf hangers, with leakage-proof function, firm and practical;

•  Fireproof vent, effectively dilute the concentration of volatile substances to prevent fire hazards;

•  Industrial standard 5cm bottom sump containment to prevent liquid spillage;

•  High quality reflective warning label for improving safety of cabinet in a weak-light area;

•  In terms of OSHA, on outside side panel, there is built-in grounding static connector for easy grounding;

•  Self-closing door can shut and latch automatically when a fusible link melts at 74 degree under fire conditions.

Specification

Model No. (manual door)

TEK610045B

Model No. (self-closing door)

TEK610045BS

Color

Blue

Material Specifications

CR steel plate

Volume  (Gal/L)

45/ 170

Door Type

Double

Adjustable Shelves(pcs)

2

Shelf Loading Weight(Kgs)

100

Ext. Dimension (HxWxD/mm)

1650x1090x460

Packing Dimension (HxWxD/mm)

1790x1160x530

Net Weight(Kgs)

95

Gross Weight (Kgs)

119
